VEVOR Air Curtain 47-Inch Commercial Air Curtain 2 Speeds Door Air Curtain 2014 CFM/1832 CFM with 2 Limited Switches Low Noise Indoor Air Curtain
Highlights:
1.Isolate Interior from Exterior: UL & CE certified. The air curtain creates a high-speed airflow at the entrance to isolate the inside and outside air environment and avoid 90% of hot or cold air, smoke, and exhaust gas. NOTE: Air curtain is not a wall mount air conditioner. It can not bring cold or hot air.
2.2 Speeds At Lo/Off/Hi Switch: High speed: 2014 CFM (power: 447W); Low speed: 1832 CFM (power: 341W). You can switch between two speeds as you wish. Pure copper motors consume less power than other commercial air curtains.
3.2 Limit Switches Included: Roller plunger micro switch and adjustable roller lever arm limit switch for easy door mounting. The indoor air curtain automatically opens when the door is opened and closes when the door is closed.
4.Easy Installation: This air curtain is suitable for 137.8" (3.5 m) high doors. Referring to the user manual, attach the mounting plate securely, hang the air curtain, install the optional door switch, and connect to the dedicated two wires.
5.Low Noise & High Applicability: The newly designed air curtain achieves quiet operation (<=60dB) and is ideal for installation at the entrance of shopping malls, restaurants, supermarkets, and lobbies.
Details:
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
1.Isolate Interior from Exterior: UL & CE certified. The air curtain creates a high-speed airflow at the entrance to isolate the inside and outside air environment and avoid 90% of hot or cold air, smoke, and exhaust gas. NOTE: Air curtain is not a wall mount air conditioner. It can not bring cold or hot air.
2.2 Speeds At Lo/Off/Hi Switch: High speed: 2014 CFM (power: 447W); Low speed: 1832 CFM (power: 341W). You can switch between two speeds as you wish. Pure copper motors consume less power than other commercial air curtains.
3.2 Limit Switches Included: Roller plunger micro switch and adjustable roller lever arm limit switch for easy door mounting. The indoor air curtain automatically opens when the door is opened and closes when the door is closed.
4.Easy Installation: This air curtain is suitable for 137.8" (3.5 m) high doors. Referring to the user manual, attach the mounting plate securely, hang the air curtain, install the optional door switch, and connect to the dedicated two wires.
5.Low Noise & High Applicability: The newly designed air curtain achieves quiet operation (<=60dB) and is ideal for installation at the entrance of shopping malls, restaurants, supermarkets, and lobbies.
Details:
Commercial Air Curtain
Air curtain is a powerful fan that creates an invisible high-speed air barrier over the entrance to isolate the interior and exterior air environment and maintain temperature separation. It is energy-saving and helps to prevent the conditioned air escape to the exterior, and block the entry of flying insects, dust, hot/cold air and smokes.
- Isolate Interior From Exterior
- 2 Speeds At Low/Off/High Switch
- Large Air Flow & Low Noise
- 2 Limit Switches Included
Tough Equipment & Tools, Pay Less
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, VEVOR has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
- Premium Tough Quality
- Incredibly Low Prices
- Fast & Secure Delivery
- 30-Day Free Returns
- 24/7 Attentive Service
Tough Equipment & Tools, Pay Less
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, VEVOR has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
- Premium Tough Quality
- Incredibly Low Prices
- Fast & Secure Delivery
- 30-Day Free Returns
- 24/7 Attentive Service
Air Isolation
The wind curtains effectively prevent the conditioned air from escaping to the exterior and blocking the entry of dust, flying insects, smoke, etc.
2 Adjustable Speeds
The air curtains for doors are equipped with a button (low/off/high) to change the speed of the wind. With a high speed of 2014 CFM, and a low speed of 1832 CFM.
Large Air Flow
The high-power motor ensures large airflow. The wind deflector design is adopted, and the wind direction can be adjusted by hands to adapt to various environments.
Low Noise
The air conditioner curtain is equipped with silent bearings for quiet operation. The noise level is below 60 dB, allowing it to be operated in a quiet environment.
Energy-Saving Design
The limit switch can be installed on the door. When the door is opened, the door fan automatically starts to work, and when the door is closed, it automatically closes.
Easy To Install
It comes with a mounting plate, which is already equipped with pre-drilled holes that meet the installation standards, making installation easier and more robust.
Specifications
- Air Flow: 1832-2014 CFM
- Input Power: 341-447 W
- Wind Speed: 10-11m/s
- Noise: <60 dB
- Motor HP: 2/5-3/5
- Use Voltage:110V/60HZ
- Suitable Door Height: 137.8" (3.5m)
- Power Cord Length: 59"+71" (1.5+1.8m)
- Net Weight: 38.6 lbs (17.5 kg)
- Product Dimensions: 47.2"x10.2"x10.6" (1200x260x270mm)
Package Content
- 1 x Air Curtain
- 2 x Limit Switches
- a Set of Installation Tools
Tough Equipment & Tools, Pay Less
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, VEVOR has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
- Premium Tough Quality
- Incredibly Low Prices
- Fast & Secure Delivery
- 30-Day Free Returns
- 24/7 Attentive Service
Tough Equipment & Tools, Pay Less
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, VEVOR has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
- Premium Tough Quality
- Incredibly Low Prices
- Fast & Secure Delivery
- 30-Day Free Returns
- 24/7 Attentive Service
Commercial Air Curtain
Air curtain is a powerful fan that creates an invisible high-speed air barrier over the entrance to isolate the interior and exterior air environment and maintain temperature separation. It is energy-saving and helps to prevent the conditioned air escape to the exterior, and block the entry of flying insects, dust, hot/cold air and smokes.
- Isolate Interior From Exterior
- 2 Speeds At Low/Off/High Switch
- Large Air Flow & Low Noise
- 2 Limit Switches Included
Air Isolation
The wind curtains effectively prevent the conditioned air from escaping to the exterior and blocking the entry of dust, flying insects, smoke, etc.
2 Adjustable Speeds
The air curtains for doors are equipped with a button (low/off/high) to change the speed of the wind. With a high speed of 2014 CFM, and a low speed of 1832 CFM.
Large Air Flow
The high-power motor ensures large airflow. The wind deflector design is adopted, and the wind direction can be adjusted by hands to adapt to various environments.
Low Noise
The air conditioner curtain is equipped with silent bearings for quiet operation. The noise level is below 60 dB, allowing it to be operated in a quiet environment.
Energy-Saving Design
The limit switch can be installed on the door. When the door is opened, the door fan automatically starts to work, and when the door is closed, it automatically closes.
Easy To Install
It comes with a mounting plate, which is already equipped with pre-drilled holes that meet the installation standards, making installation easier and more robust.
Package Content
- 1 x Air Curtain
- 2 x Limit Switches
- a Set of Installation Tools
Specifications
- Air Flow: 1832-2014 CFM
- Input Power: 341-447 W
- Wind Speed: 10-11m/s
- Noise: <60 dB
- Motor HP: 2/5-3/5
- Use Voltage:110V/60HZ
- Suitable Door Height: 137.8" (3.5m)
- Power Cord Length: 59"+71" (1.5+1.8m)
- Net Weight: 38.6 lbs (17.5 kg)
- Product Dimensions: 47.2"x10.2"x10.6" (1200x260x270mm)
